1.8degree two-phase 42mm hybrid stepper motor

Product Categories
Jiangsu Changzhou Sutai Electrical Appliance Co.,Ltd
Contact Now

1.8degree two-phase 42mm hybrid stepper motor

Place of Origin : China

Brand Name : Sutai

Certification : ISO9001-2008,CE,TUV,ROHS

Model Number : ST-42H

Step Angle(degrees) : 1.8

stepper motor length : 28-60

phase inductance : 2.3-26.5

stepper motor holding torque : 1.8-8

Holding Torque : 1.6~8

rated current : 1.2-2.1

stepper motor lead wire : 4/6

Current / Phase : 0.4-2.1

stepper motor phase resistance : 1.5-24.5

MOQ : 1

Price : FOB,CIF

Packaging Details : use export carton, pallet or according to customer's request

Delivery Time : 30days

Payment Terms : L/C,T/T

Supply Ability : 10000per month

Contact Now

ries Model Step angel Motor lengh Rated Current Phase Resistance Phase Inductance Holding torque Rotor Inertia Lead wire Motor weight
42H200 1.8 29 1 2 1.5 1.8 28 4 185
42H309 1.8 34 0.6 4.3 6.3 2.2 34 4 220
42H310 1.8 34 1 2.15 2.4 2.2 34 4 220
42H330 1.8 34 0.4 30 30 2.2 34 4 220
42H360 1.8 34 1 4.4 2.75 1.6 34 6 220
42H361 1.8 34 0.85 4.27 3.4 1.6 34 6 220
42H363 1.8 34 0.4 24.5 17 1.6 34 6 220
42H401 1.8 40 1.7 1.5 2.7 3.9 54 4 290
42H462 1.8 40 1.2 3.2 2.8 2.6 54 6 290
42H463 1.8 40 0.41 30 24 2.6 54 6 290
42H4812 1.8 48 1.2 3.2 4.2 4.4 68 4 360
42H4820 1.8 48 1.7 1.8 2.8 4.4 68 4 360
42H4861 1.8 48 1.26 4.2 3.9 3.2 68 6 360
42H4863 1.8 48 0.4 30 26.5 3.2 68 6 360
42H4866 1.8 48 0.8 7.6 8.4 3.2 68 6 360
42H640 1.8 60 0.64 15 13.2 6 82 4 450
42H643 1.8 60 2.1 1.6 3 6.5 82 4 450

1.8degree nema17 2 phase 42mm small stepper motor

Specifications of stepper motor

42mm NEMA17 2phase hybrid stepper motor
42mm small size stepper motor for monitoring equipment

Hybird Stepper Motors
1) CE, RoHS and TUV approved
2) All above are our conventional products,special products can be customized according to the customer requirements.

Applications of stepper motor:

Use for robots stepper motor,3Dprinter,electronic automatic equipment stepper motor ,medical instrument stepper motor,

advertisement instrument stepper motor,lighting&audio equipment stepper motor ,printer stepper motor,textile machinery stepper motor.

Cnc router stepper motor.

1.8degree two-phase 42mm hybrid stepper motor

1.8degree two-phase 42mm hybrid stepper motor

1.8degree two-phase 42mm hybrid stepper motor-+

Recommend stepper motor driver

1.8degree two-phase 42mm hybrid stepper motor1.8degree two-phase 42mm hybrid stepper motor

Certifications of stepper motor

1.8degree two-phase 42mm hybrid stepper motor

Why choose us?

1.Our products have approved ISO,CE,ROHS,TUV certification.

2. specialized in the development, manufacture stepping motors with well-equipped testing equipment and strong technical force.

3."High quality products, competitive prices, and excellent customer services" are always our ultimate goals.

4. Creating a win-win business relationship with you in the near future.

costumer Jinting
1. Can I have customized stepper motors? Yes, you can. Please let me know your special requirements.
2. How to get the quotation as soon as possible? Please provide the information as below:
A: What is the size of stepper motor? Generally, it is 20,28,35,39, 42, 57,60,86,110 mm.
B: What is the length and diameter of output shaft? It depends on your requirement, if you have no data about this, we will give you some suggestions.
C: How many lead wires are there? It depends on your requirement, if you have no data about this, we will give you some suggestions.
D: What is the phrase? Here are 2, 3, 4 ,5phrase for choice.
E: What is the step angle? Here are 1.8, 0.9, 1.2 ,1.5for choice.
FAQ

More Information for Customers:

1.Q:Can I get some samples?

A:We are honored to offer you samples for quality check.
